1) Output : 8W/1W
2) Frequency Range: 136.00-174.00 MHz & 400.00-520.00MHz
3) Frequency Step Setting
4) High &Low Power Switchover
5) Battery Saving
6) VOX Function
7) Wide/Narrow Band Selection
8) Auto-Back Light
9) Dual Band Standby
10) Time-out Timer (TOT)
11) 50 CTCSS and 104 DCS Codes
12) Voice Prompt
13) ANI Code
14) PC or Manual Program
15) DTMF Code
16) PTT-ID
17) ATUO Keypad Lock
18) Busy Channel Lock Function
19) Dual Band, Dual Display and Dual Standby
20) Emergency Alarm
21) Priory Scanning Function
22) Relay Forwarding Confirmed (1750 HZ)
23) Low Battery Warning
24) U/V Cross Band Dual Watch
Specifications:
| General |
| Frequency Range | 65MHz-108MHz(Only commercial FM radio reception)
VHF:136MHz-174MHz(Rx/Tx)
UHF:400MHz-520MHz(Rx/Tx) |
| Memory Channel | Up to 128 Channels |
| Frequency Step | 2.5KHz/5KHz/6.25KHz/10KHz/12.5KHz/20KHz/25KHz |
| Operated Voltage | DC 7.4V |
| Battery capacity | 2200MAh Li-ion |
| Duty cycle | 03/03/54min.(Rx/Tx/Standby) |
| Frequency Stability | ±2.5ppm |
| Operated Temperature | -20°C to +55°C |
| Antenna Impedance | 50Ω |
| Dimensions (L×W×H) | 121*64*36mm (not including antenna) |
| Weight | 165g (not including battery & antenna) |
| Consumption in standby | 380mA |
| Communication Range | about 5-8km |
| Receiver | Wide band | Narrow band |
| Sensitivity (12dB SINAD) | ≤0.20 uV | ≤0.20 uV |
| Intermodulation | ≥60dB | ≥60dB |
| Spurious Response | ≥65dB | ≥65dB |
| Maximum deviation | ≤±5kHz | ≤±2.5kHz |
| Audio Power Output | 1W | 1W |
| Transmitter | Wide band | Narrow band |
| RF Power Output | 8W/1W |
| Type of modulation | FM |
| Maximum deviation | ≤±5KHz | ≤±2.5KHz |
| Emission class | 16kΦF3E | 11kΦF3E |
| Spurious Emission | <-60dB | <-60dB |
Package Include:
1 x Portable radio
1 x Antenna
1 x Li-ion battery pack
1 x Charger (EU,US,UK,AU avaliable)
1 x Adaptor
1 x Earpiece
1 x Belt clip
1 x Sling
1 x User´s manual
Our Services
Service
1. OEM & ODM serivice offered
2. Sample's fee can be refund after order reached 1000 sets.
3.Delivery can be Express:DHL,UPS, FedEx, EMS, TNT and etc.
Warranty
Before delivery , we will check the items' quality strictly one by
one . * 12 months for radio body & 6month for accessories warranty,
please contact us immediately when you get defective,thanks!
